1/2 JAMESBURY THD HIGH
Jamesbury™ Value-Line™ 5H MA0012395 Ball Valve, 1/2 IN, Threaded, Carbon Steel, 4500 PSI
- Manufacturer: Valmet
- Brand: Jamesbury
- MGPN: J 5H-22HBRT 1/2
- MPN: MA0012395
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
The Jamesbury™ Value-Line Series 5H ball valve is a screwed end valve designed specifically for handling a wide range of fluids and gases at higher pressures. It incorporates a unique flexible lip seat design to provide long-lasting tight shut-off at pressures to 4500 PSI (310 BAR) in sizes 1/4 - 1 IN (DN 8 - 25) and 3000 PSI (206 BAR) in sizes 1-1/4 - 2 IN (DN 32 - 50).
Jamesbury™ Value-Line™ 5H 2-Piece Standard Port Ball Valve, 1/2 IN Nominal, Threaded Connection, 4500 PSI, 230 DEG F, 1/2 IN Opening, Carbon Steel Body, Locking Lever Handle Operator, Carbon Steel Handle, 17-4 PH Stainless Steel Stem, Acetal Homopolymer Trim, Acetal Homopolymer Seat, PTFE Seal, Other Physical Dimension: 2.73 IN Inlet To Outlet Length, 2.26 IN Top To Inlet Center
| Sub Brand | : | Value-Line™ |
| Item Name | : | Ball Valve |
| Type | : | 2-Piece, Standard Port |
| Series/Model | : | 5H |
| Nominal Size | : | 1/2 IN |
| Connection Type | : | Threaded |
| Pressure Rating | : | 4500 PSI |
| Temperature Rating | : | 230 DEG F |
| Opening Size | : | 1/2 IN |
| Body Material | : | Carbon Steel |
| Operator Type | : | Locking Lever Handle |
| Handle Material | : | Carbon Steel |
| Stem Material | : | 17-4 PH Stainless Steel |
| Trim Material | : | Acetal Homopolymer |
| Seat Material | : | Acetal Homopolymer |
| Seal Material | : | PTFE |
| Other Physical Dimension | : | 2.73 IN Inlet To Outlet Length, 2.26 IN Top To Inlet Center |
- Robust engineering design
- Self-relieving seat technology
- Long service life
- Ability to withstand high pressures
- Bi-directional in hazardous media service
- Bubble tight shut-off
- Automatable
