2-1/2X1/2 COPPER PRESS TEE
Apollo Press® Model 811RXL 10077763 Reducing Tee, 2-1/2 X 2-1/2 X 1/2 IN, Press, Copper
- Manufacturer: Aalberts integrated piping systems (CONBRACO)
- Brand: Apollo Press
- MGPN: APOLLO PRESS TEE CXC 2-1/2X1/2
- MPN: 10077763
- UPC: 683264777637
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
The ApolloPress® 811R large diameter press reducing outlet tee features a lead-free dezincification-resistant copper body, a patented stainless steel solid cross section grab ring, a nylon separation ring and an EPDM O-ring. ApolloPress® products are manufactured utilizing proven ASTM materials and standards.
Apollo Press® Reducing Tee, Reducing Tee, Series/Model: Model 811RXL, 2-1/2 X 2-1/2 X 1/2 IN Nominal, Connection Type: Press, Copper, Material Specification: UNS C12200, 5.18 IN Length, 300 PSI Maximum Pressure, 32 - 250 DEG F, Industry Standards: CRN, FM Approved, IAPMO/ANSI/CAN Z1117, ICC LC1002, NSF/ANSI-372, NSF/ANSI-61, Other Physical Dimension: 2.81 X 2.37 X 2.81 IN Center To End, Lead Free: Yes, 1.700 LB Weight
| Item Name | : | Reducing Tee |
| Series/Model | : | Model 811RXL |
| Nominal Size | : | 2-1/2 X 2-1/2 X 1/2 IN |
| Connection Type | : | Press |
| Material | : | Copper |
| Material Specification | : | UNS C12200 |
| Length | : | 5.18 IN |
| Maximum Pressure | : | 300 PSI |
| Temperature Rating | : | 32 - 250 DEG F |
| Industry Standards | : | CRN, FM Approved, IAPMO/ANSI/CAN Z1117, ICC LC1002, NSF/ANSI-372, NSF/ANSI-61 |
| Other Physical Dimension | : | 2.81 X 2.37 X 2.81 IN Center To End |
| Lead Free | : | Yes |
| Weight | : | 1.700 LB |
- Lead-free construction
- Leak Before Press® technology
- Visual element, break away band
