WEKSLER COMMERCIAL GAUGE
Weksler Model EA14 EA14L Contractor Gauge, 4-1/2 IN Dial, 30 - 0 IN Hg, 0 - 30 PSI, 1/4 IN MNPT Bottom
- Manufacturer: Ashcroft Inc
- Brand: Weksler
- MGPN: GAEA14L 30-0-150
- MPN: EA14L
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
Weksler Contractor Gauge, Contractor Gauge, Series/Model: Model EA14, 4-1/2 IN Dial, 30 - 0 IN Hg, 0 - 30 PSI Measuring, Units Of Measure: IN Hg, PSI, 1/4 IN MNPT Bottom Connection, Plus/Minus 2-1-2% Of Span Accuracy, Graduations: 5 IN Hg, 5 PSI, Stainless Steel Case, Plastic Lens, Movement Material: Brass/Bronze, Bronze Tube, Brass Socket, Finish/Color: Black, Filled With: Dry, 4-15/16 IN Length, 4-15/16 IN Width, 1-3/16 IN Depth
| Item Name | : | Contractor Gauge |
| Series/Model | : | Model EA14 |
| Dial Size | : | 4-1/2 IN |
| Measuring Range | : | 30 - 0 IN Hg, 0 - 30 PSI |
| Units Of Measure | : | IN Hg, PSI |
| Connection | : | 1/4 IN MNPT Bottom |
| Accuracy | : | Plus/Minus 2-1-2% Of Span |
| Graduations | : | 5 IN Hg, 5 PSI |
| Case Material | : | Stainless Steel |
| Lens Material | : | Plastic |
| Movement Material | : | Brass/Bronze |
| Tube Material | : | Bronze |
| Socket Material | : | Brass |
| Finish/Color | : | Black |
| Filled With | : | Dry |
| Length | : | 4-15/16 IN |
| Width | : | 4-15/16 IN |
| Depth | : | 1-3/16 IN |
- Corrosion-resistant stainless steel case and ring, plastic lens
- Zero adjusting screw
- Soft soldered phosphor bronze tube with brass socket
- Suitable for steam, water, air, oil, gas or any medium not corrosive to copper alloys
- Bronze/brass movement
- Easy-to-read dial, white background with bold black numerals and graduations, 270 DEG arc
- 1/4 IN NPT bottom connection only
