5 VIC 003 PAINTED FIRELOCK 45 ELBOW
Victaulic FireLock™ Model 003 F050003P00 45 DEG Elbow, 5 IN, Grooved, Ductile Iron, Orange Enamel Coated, 5.56 IN OD
- Manufacturer: Victaulic Company
- Brand: Victaulic
- MGPN: 500P00345
- MPN: F050003P00
- UPC: 688304059308
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
Victaulic FireLock™ 45 DEG Elbow, FireLock™, 45 DEG Elbow, Series/Model: Model 003, 5 IN Nominal, Connection Type: Grooved, 5.56 IN Outside Diameter, Ductile Iron, Material Standard: ASTM A536 Grade 65-45-12, Finish/Color: Orange Enamel Coated, Industry Standards: cULus Listed, FM Approved, VDS Compliant, LPCB, CE EN 10311 CPR (EU) No 305/2011, UKCA BS EN 10311 CPR (UK) 2019 No 465, EAC, Other Physical Dimension: 3-1/4 IN Center To End, 8.300 LB Weight
| Sub Brand | : | FireLock™ |
| Item Name | : | 45 DEG Elbow |
| Series/Model | : | Model 003 |
| Nominal Size | : | 5 IN |
| Connection Type | : | Grooved |
| Outside Diameter | : | 5.56 IN |
| Material | : | Ductile Iron |
| Material Standard | : | ASTM A536 Grade 65-45-12 |
| Finish/Color | : | Orange Enamel Coated |
| Industry Standards | : | cULus Listed, FM Approved, VDS Compliant, LPCB, CE EN 10311 CPR (EU) No 305/2011, UKCA BS EN 10311 CPR (UK) 2019 No 465, EAC |
| Other Physical Dimension | : | 3-1/4 IN Center To End |
| Weight | : | 8.300 LB |
- FireLock full flow elbows and tees feature CAD-developed, hydrodynamic design, affording a shorter center-to-end dimension than standard fittings
- Noticeable bulge allows the water to make a smoother turn to maintain similar flow characteristics as standard full flow fittings
