1/2 VIC 78BL THRD LF BALANCING BALL VLV
Victaulic Series 78BL V00478BLFF Balancing Valve, 1/2 IN, FNPT, Brass, 400 PSI, 0.38 - 5.3 GPM
- Manufacturer: Victaulic Company
- Brand: Victaulic
- MGPN: 05078BLTBV
- MPN: V00478BLFF
- UPC: 883481585415
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
Victaulic Balancing Valve, Item Name: Balancing Valve, Series/Model: Series 78BL, 1/2 IN Nominal, FNPT Connection, 400 PSI, 0.38 - 5.3 GPM Flow Rate, -20 - 120 DEG C, Brass Body, Zinc-Plated Carbon Steel Handle, Stainless Steel Stem, PTFE Seat, EPDM Seal, Industry Standards: IAPMO Listed in Accordance With ANSI/NSF-61, Lead Free: Yes, Other Physical Dimension: 2.38 IN Inlet to Outlet Length, 1-1/2 IN Top to Inlet Center
| Item Name | : | Balancing Valve |
| Series/Model | : | Series 78BL |
| Nominal Size | : | 1/2 IN |
| Connection Type | : | FNPT |
| Pressure Rating | : | 400 PSI |
| Flow Rate | : | 0.38 - 5.3 GPM |
| Temperature Rating | : | -20 - 120 DEG C |
| Body Material | : | Brass |
| Handle Material | : | Zinc-Plated Carbon Steel |
| Stem Material | : | Stainless Steel |
| Seat Material | : | PTFE |
| Seal Material | : | EPDM |
| Industry Standards | : | IAPMO Listed in Accordance With ANSI/NSF-61 |
| Lead Free | : | Yes |
| Other Physical Dimension | : | 2.38 IN Inlet to Outlet Length, 1-1/2 IN Top to Inlet Center |
- Shut-off, manual throttling and measuring valve with reduced port
