10 VELAN F1064C-02TY GATE
Velan F16-1064C-02TY Gate Valve, 10 IN, Flanged, Class 300, Wrought Carbon Steel Body
- Manufacturer: Velan Valve Corporation
- Brand: Velan
- MGPN: VLV GT CS 300 FLGD 10
- MPN: F16-1064C-02TY
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
Velan bolted bonnet flexible wedge gate valves are ideal for high pressure steam, catalytic reformers, hydrocrackers and other tough services.
Velan Gate Valve, Type: Bolted Bonnet Forged Flexible Wedge, Full-Port, Gate Valve, 10 IN Nominal, Connection Type: Flanged, Pressure Class: Class 300, Wrought Carbon Steel Body, Handwheel Operator, Stainless Steel Stem, Stainless Steel Trim, Stainless Steel Alloy Seat, Material Standard: ASTM A105 Grade WCB
| Item Name | : | Gate Valve |
| Type | : | Bolted Bonnet Forged Flexible Wedge, Full-Port |
| Nominal Size | : | 10 IN |
| Connection Type | : | Flanged |
| Pressure Class | : | Class 300 |
| Body Material | : | Wrought Carbon Steel |
| Operator Type | : | Handwheel |
| Stem Material | : | Stainless Steel |
| Trim Material | : | Stainless Steel |
| Seat Material | : | Stainless Steel Alloy |
| Material Standard | : | ASTM A105 Grade WCB |
- Stronger, leak-proof bolted body bonnet joint ensures joint tightness with a higher bolting torque
- Wedge guiding minimizes seat rubbing and scuffing resulting in long cycle life
- Designed to ASME B16.34
- Body made of superior strength forgings and optional cast steel
- Velan stem seal offers tight seal with little to no maintenance over long periods of time
- Optional live-loading of packing and leak-off
- Non-rotating stem
- Hard faced seating faces-resist erosion
Brochure/Catalog Name
