3/4 SW SARCO CT Y-STRAINER CS WITH 20 MESH SCREEN
Spirax Sarco CT Carbon Steel 20 Mesh Y-Strainer, 3/4 IN, Socket Weld
- Manufacturer: Spirax Sarco Inc
- Brand: Spirax Sarco
- MGPN: S52082
- MPN: 52082
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
| Item Name | : | Y-Strainer |
| Series/Model | : | Series CT |
| Nominal Size | : | 3/4 IN |
| Connection Type | : | Socket Weld |
| Screen Size | : | 20 Mesh |
| Blow-Off Port Size | : | 3/8 IN |
| Pressure Class | : | Class 600 |
| Pressure Rating | : | 984 PSIG |
| Body Material | : | Carbon Steel |
| Screen Material | : | 304 Stainless Steel |
| Material Standard | : | ASME B31.3, ASTM A216 Grade WBC, Cap: ASTM A108 |
| Temperature Rating | : | 750 DEG C Maximum Allowable |
| Width | : | 8.1 IN |
| Other Physical Dimension | : | 4.4 IN Inlet To Outlet |
| Additional Specifications | : | Flow Co-Efficient (Cv): 11.5, Area: 4 Sq-IN |
- High efficiency steam strainers & filters for better quality steam
- Designed to remove solid particles from the steam supply
- Reduce levels of contamination
- Maintain quality of end product
