1-1/4 NIBCO T580-70-UL THD BALL VALVE
NIBCO T-580-70-UL NL9502B Ball Valve, 1-1/4 IN, FPT, Bronze, 250 PSI
- Manufacturer: NIBCO
- Brand: NIBCO
- MGPN: VLV BA BR T58070 UL 1-1/4
- MPN: NL9502B
- UPC: 039923675729
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
The NIBCO bronze ball valve provides bubble tight shut-off at 250 PSI. The 2-piece valve is designed to be used on gasoline, fuel oil, LP gas and is UL listed for flammable fluids.
NIBCO T-580-70-UL 2-Piece Conventional Port Quarter-Turn Ball Valve, 1-1/4 IN Nominal, FPT Connection, 250 PSI, Bronze Body, Standard Lever Handle Operator, Zinc-Plated Steel Handle, Silicon Bronze Stem, Bronze Trim, PTFE Packing, Brass Gland, RPTFE Seat, Material Standard: ASTM B584, ASTM A124, ASTM A371, Industry Standards: MSS-SP110, CSA ANSI/ASME B16.33, cUL YSDT7, UL842, Other Physical Dimension: 3.94 IN Inlet To Outlet Length, 6-3/4 IN Top To Inlet Center
| Brand Name | : | NIBCO |
| Item Name | : | Ball Valve |
| Type | : | 2-Piece, Conventional Port, Quarter-Turn |
| Series/Model | : | T-580-70-UL |
| Nominal Size | : | 1-1/4 IN |
| Connection Type | : | FPT |
| Pressure Rating | : | 250 PSI |
| Body Material | : | Bronze |
| Operator Type | : | Standard Lever Handle |
| Handle Material | : | Zinc-Plated Steel |
| Stem Material | : | Silicon Bronze |
| Trim Material | : | Bronze |
| Packing Material | : | PTFE |
| Gland Material | : | Brass |
| Seat Material | : | RPTFE |
| Material Standard | : | ASTM B584, ASTM A124, ASTM A371 |
| Industry Standards | : | MSS-SP110, CSA ANSI/ASME B16.33, cUL YSDT7, UL842 |
| Other Physical Dimension | : | 3.94 IN Inlet To Outlet Length, 6-3/4 IN Top To Inlet Center |
- Valve pressure rating 250 PSI/17.2 BAR non-shock LP gas per UL842
- Blowout-proof stem design
- Standard lever handle
- Dezincification-resistant
