4-1/2 0-3000 PSI PRESSURE GAUGE 1/2 LM

Marsh Process gauges are first in performance. With over 125 YR of proven experience, Marsh offers the most complete line of process instrumentation in the industry. An extensive list of designs and options makes the Marsh line of process gauges the intelligent and practical choice in process instrumentation. All case styles feature SAFECASE solid-front construction.

Turret Style Process Pressure Gauge, 4-1/2 IN Dial, Measuring Range: 0 - 3000 PSI, Units Of Measure: PSI, Connection: 1/2 IN NPT Lower, Accuracy: Plus/Minus 0.5% Full Scale (ASME Grade 2A), Graduations: 20 Smallest, 500 Largest, Dial Face: Black Markings On White, Polypropylene Case, Acrylic Lens, Pointer Material: Black Aluminum, Stainless Steel Movement, Tube Material: Copper Alloy, Copper Alloy Socket, Length: 5.85 IN, 5.85 IN Width, 3.13 IN Depth

• 4-1/2 IN and 6 IN dials
• 4 SAFECASE designs
• Pressure ranges vacuum to 20000 PSI
• Dry or liquid filled
• Micrometer pointer

• Catalog https://www.macombgroup.com//ASSETS/DOCUMENTS/ITEMS/EN/MarshBellofram_G22675_Catalog.pdf
• Specification Sheet https://www.macombgroup.com//ASSETS/DOCUMENTS/ITEMS/EN/4500100PPG_Spec.pdf
