16 11303WE 1500 GATE VALVE S160

Gate Valve, Series/Model: Model 11303WE, Nominal Size: 16 IN, Connection Type: Buttweld, Class 1500 Pressure Class, Carbon Steel Body Material, Handwheel Operator Type, Handle Material: Malleable Iron, Stem Material: Stainless Steel, Brass Gland, Material Standard: Body: ASTM A216 Grade WCB, Stem: ASTM A182 Grade F6A, Gland: ASTM B16, Handle: ASTM A47 Grade 32510, Industry Standards: ASME B16.25, 816.10, 47 IN Width, Lead Free: No, Other Physical Dimension: 98 IN Inlet Center To Top Of Valve

• Flexible wedge H type wedge, which is stellite faced, prevents sticking when valves are closed hot
• Stellite faced seat rings are accurately machined, pressed and welded in place
• Stellite faced back seat area and stem guide insure tight sealing and accurate guiding of stem
• Yoke arm design studs and nuts hold the yoke arm to the body, this eliminates the need of a heavy clamp, and maintains perfect alignment and rigidity of yoke arm to the body
• Swing eyebolts provide easy access to the packing chamber
• Body has a streamlined passage which produces maximum flow with minimum turbulence
• Lifting lugs, an exclusive powell feature, are cast on the yoke arm of larger size valves to facilitate handling during erection and in maintenance
• Carbon steel gland flange, steel eye bolts, groove pin, steel/stellite Seat facing ring

• Specification https://www.macombgroup.com//ASSETS/DOCUMENTS/ITEMS/EN/160011303WEGV_Spec.pdf
