1 JAMESBURY THD FIRE TITE

Clincher Series 2000 ball valves are rugged high-performance threaded end ball valves designed to handle an extremely wide variety of liquids, gases and slurries. These compact valves have a two-piece body construction which aids in piping system dis assembly and are available with temperature ratings from -60 to +500 DEG F (-51 to +260 DEG C), depending on materials. The body style 21 is manufactured in brass. The Fire-Tite™ Series 23 is available in carbon steel or stainless steel. Clincher Series 2000 style 21 valves are available specially prepared for critical services such as oxygen and high-vacuum. Also available are valves conforming to UL approved configurations.

Jamesbury™ Ball Valve, Sub Brand: Clincher™ Fire-Tite, Item Name: Ball Valve, Series/Model: 2000, 1 IN Nominal, Threaded Connection, 800 - 1200 PSI, 500 DEG F, 0.88 IN Opening, Carbon Steel Body, Lever Operator, Carbon Steel Handle, Stainless Steel Stem, Stainless Steel Trim, PTFE Seat, PTFE Seal, Material Standard: ASTM A193, 2.44 IN Width, Other Physical Dimension: 3.41 IN Inlet To Outlet Length, 2-1/2 IN Top To Inlet Center, Brand: Jamesbury™

• Robust engineering design
• Self-relieving seat technology
• High-quality
• Long service life
• Bi-directional in hazardous media service
• Bubble tight shut-off
• Automatable

• Installation Instruction Name https://www.macombgroup.com//ASSETS/DOCUMENTS/ITEMS/EN/J232236MT1_Inst.pdf
• Specification Name https://www.macombgroup.com//ASSETS/DOCUMENTS/ITEMS/EN/J232236MT1_Spec.pdf
