3/8 JAMESBURY THD CLINCHER
Jamesbury™ Clincher™ 2000 MA0010760 Ball Valve, 3/8 IN, Threaded, Brass, 800 PSI
- Manufacturer: Valmet
- Brand: Jamesbury
- MGPN: J 21-1136TT 3/8
- MPN: MA0010760
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
Clincher Series 2000 ball valves are rugged high-performance threaded end ball valves designed to handle an extremely wide variety of liquids, gases and slurries. These compact valves have a 2-piece body construction which aids in piping system disassembly and are available with temperature ratings from -60 - 500 DEG F. Depending on materials. The body style 21 is manufactured in brass.
Jamesbury™ Clincher™ 2000 2-Piece Standard Port Ball Valve, 3/8 IN Nominal, Threaded Connection, 800 PSI, 500 DEG F, Brass Body, Brass Stem, Brass Trim, PTFE Seat, PTFE Seal, Material Standard: ASTM B124, ASTM A449, Other Physical Dimension: 2.34 IN Inlet To Outlet Length, 1.78 IN Top To Inlet Center
| Brand Name | : | Jamesbury™ |
| Sub Brand | : | Clincher™ |
| Item Name | : | Ball Valve |
| Type | : | 2-Piece, Standard Port |
| Series/Model | : | 2000 |
| Nominal Size | : | 3/8 IN |
| Connection Type | : | Threaded |
| Pressure Rating | : | 800 PSI |
| Temperature Rating | : | 500 DEG F |
| Body Material | : | Brass |
| Stem Material | : | Brass |
| Trim Material | : | Brass |
| Seat Material | : | PTFE |
| Seal Material | : | PTFE |
| Material Standard | : | ASTM B124, ASTM A449 |
| Other Physical Dimension | : | 2.34 IN Inlet To Outlet Length, 1.78 IN Top To Inlet Center |
- Robust engineering design
- Self-relieving seat technology
- Long service life
- Bi-directional in hazardous media service
- Bubble tight shut-off
- Automatable
