ASHCROFT GAUGE
Ashcroft® Model 1008A/AL 631008A02B100# Pressure Gauge, 2-1/2 IN Dial, 0 - 100 PSI, 1/4 IN MNPT Center Back
- Manufacturer: Ashcroft Inc
- Brand: Ashcroft
- MGPN: GA631008A02B 0-100
- MPN: 631008A02B100#
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
The Ashcroft® 1008A/AL pressure gauge offers exceptional quality, durability, and performance. The sealed case protects from ambient conditions, and includes features enhancing product performance and safety. An ideal gauge for satisfying applications with high levels of vibration, pulsation, and pressure spikes.
Ashcroft® Pressure Gauge, Pressure Gauge, Series/Model: Model 1008A/AL, 2-1/2 IN Dial, 0 - 100 PSI Measuring, Units Of Measure: PSI, 1/4 IN MNPT Center Back Connection, Plus/Minus 3-2-3% Of Span (ASME B40.100 Grade B) Accuracy, Aluminum Dial Face, 304 Stainless Steel Case, Polycarbonate Lens, Aluminum Pointer, Movement Material: Polyester Segment/PowerFlex™ With Brass, Bronze Tube, Brass Socket, Filled With: Dry, -40 To 158 DEG F, 2.71 IN Length, 2.71 IN Width, 1.23 IN Depth, Industry Standards: ASME B40.100, CE Marked, CRN Approved, UKCA Approved, RoHS Compliant
| Item Name | : | Pressure Gauge |
| Series/Model | : | Model 1008A/AL |
| Dial Size | : | 2-1/2 IN |
| Measuring Range | : | 0 - 100 PSI |
| Units Of Measure | : | PSI |
| Connection | : | 1/4 IN MNPT Center Back |
| Accuracy | : | Plus/Minus 3-2-3% Of Span (ASME B40.100 Grade B) |
| Dial Face | : | Aluminum |
| Case Material | : | 304 Stainless Steel |
| Lens Material | : | Polycarbonate |
| Pointer Material | : | Aluminum |
| Movement Material | : | Polyester Segment/PowerFlex™ With Brass |
| Tube Material | : | Bronze |
| Socket Material | : | Brass |
| Filled With | : | Dry |
| Temperature Rating | : | -40 To 158 DEG F |
| Length | : | 2.71 IN |
| Width | : | 2.71 IN |
| Depth | : | 1.23 IN |
| Industry Standards | : | ASME B40.100, CE Marked, CRN Approved, UKCA Approved, RoHS Compliant |
- PowerFlex™ movement
- Meets ASME B40.100 specifications
- TrueZero™ a unique safety feature
- Ventable fill plugs
