ASHCROFT GAUGE
Ashcroft® Duragauge® Model 1379 451379RS04L3000# Pressure Gauge, 4-1/2 IN Dial, 0 - 3000 PSI, 1/2 IN MNPT Lower
- Manufacturer: Ashcroft Inc
- Brand: Ashcroft
- MGPN: GA451379RS04L 0-3000
- MPN: 451379RS04L3000#
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
The Ashcroft® 1379 Duragauge® is a high-performance ASME style pressure gauge with sizes from 4-1/2 - 8-1/2 IN with numerous safety features and ranges up to 100000 PSI. Features include a solid front aluminum case and a 10 years pressure system warranty.
Ashcroft® Duragauge® Pressure Gauge, Duragauge®, Pressure Gauge, Series/Model: Model 1379, 4-1/2 IN Dial, 0 - 3000 PSI Measuring, Units Of Measure: PSI, 1/2 IN MNPT Lower Connection, Plus/Minus 0.5% Of Span (ASME B40.100 Grade 2A) Accuracy, Aluminum Dial Face, Aluminum Case, Glass Lens, Aluminum Pointer, Movement Material: 400 Stainless Steel, 316L Stainless Steel Tube, Steel Socket, Finish/Color: Black, Filled With: Dry, Flush, Stem, Surface Mounting, -20 To 250 DEG F, 5-13/16 IN Length, 5-13/16 IN Width, 3-3/8 IN Depth, Industry Standards: ASME B40.100, CE Marked, CRN Approved, UKCA Approved
| Sub Brand | : | Duragauge® |
| Item Name | : | Pressure Gauge |
| Series/Model | : | Model 1379 |
| Dial Size | : | 4-1/2 IN |
| Measuring Range | : | 0 - 3000 PSI |
| Units Of Measure | : | PSI |
| Connection | : | 1/2 IN MNPT Lower |
| Accuracy | : | Plus/Minus 0.5% Of Span (ASME B40.100 Grade 2A) |
| Dial Face | : | Aluminum |
| Case Material | : | Aluminum |
| Lens Material | : | Glass |
| Pointer Material | : | Aluminum |
| Movement Material | : | 400 Stainless Steel |
| Tube Material | : | 316L Stainless Steel |
| Socket Material | : | Steel |
| Finish/Color | : | Black |
| Filled With | : | Dry |
| Mounting | : | Flush, Stem, Surface |
| Temperature Rating | : | -20 To 250 DEG F |
| Length | : | 5-13/16 IN |
| Width | : | 5-13/16 IN |
| Depth | : | 3-3/8 IN |
| Industry Standards | : | ASME B40.100, CE Marked, CRN Approved, UKCA Approved |
- Wide selection of bourdon tube materials, pressure connections and pressure ranges
- Solid front case design for safety
- Teflon-coated, 400 stainless steel movement
