ASHCROFT GAUGE
Ashcroft® Duragauge® Model 1377 601377AS02BXPR3-15# Pressure Gauge, 6 IN Dial, 3 - 15 PSI, 1/4 IN MNPT Back
- Manufacturer: Ashcroft Inc
- Brand: Ashcroft
- MGPN: GA451377AS04L XPR 0-100
- MPN: 601377AS02BXPR3-15#
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
The Ashcroft® 1377 Duragauge® is a high-performance ASME style process pressure gauge with sizes from 4-1/2 - 8-1/2 IN designed for panel mounting. Features include a solid front aluminum case and a 10 years pressure system warranty.
Ashcroft® Duragauge® Pressure Gauge, Duragauge®, Pressure Gauge, Series/Model: Model 1377, 6 IN Dial, 3 - 15 PSI Measuring, Units Of Measure: PSI, 1/4 IN MNPT Back Connection, Plus/Minus 0.5% Of Span (ASME B40.100 Grade 2A) Accuracy, Aluminum Case, Glass Lens, Aluminum Pointer, Movement Material: 400 Stainless Steel, Bronze Tube, Brass Socket, Finish/Color: Black, Filled With: Dry, Flush, Remote, Stem, Surface Mounting, -20 To 250 DEG F, 7-9/16 IN Length, 7-9/16 IN Width, 2-7/8 IN Depth, Industry Standards: ASME B40.100, CE Marked, CRN Approved
| Sub Brand | : | Duragauge® |
| Item Name | : | Pressure Gauge |
| Series/Model | : | Model 1377 |
| Dial Size | : | 6 IN |
| Measuring Range | : | 3 - 15 PSI |
| Units Of Measure | : | PSI |
| Connection | : | 1/4 IN MNPT Back |
| Accuracy | : | Plus/Minus 0.5% Of Span (ASME B40.100 Grade 2A) |
| Case Material | : | Aluminum |
| Lens Material | : | Glass |
| Pointer Material | : | Aluminum |
| Movement Material | : | 400 Stainless Steel |
| Tube Material | : | Bronze |
| Socket Material | : | Brass |
| Finish/Color | : | Black |
| Filled With | : | Dry |
| Mounting | : | Flush, Remote, Stem, Surface |
| Temperature Rating | : | -20 To 250 DEG F |
| Length | : | 7-9/16 IN |
| Width | : | 7-9/16 IN |
| Depth | : | 2-7/8 IN |
| Industry Standards | : | ASME B40.100, CE Marked, CRN Approved |
- Solid front safety case with pressure relief back
- Plus/minus 0.5% of span (ASME B40.100 grade 2A)
- Dial sizes 6 IN
Installation Instruction Name
