ASHCROFT GAUGE
Ashcroft® Model 1259 451259SD04L100# Pressure Gauge, 4-1/2 IN Dial, 0 - 100 PSI, 1/2 IN MNPT Lower, Glass Lens
- Manufacturer: Ashcroft Inc
- Brand: Ashcroft
- MGPN: GA451259SD04L 0-100
- MPN: 451259SD04L100#
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
The Ashcroft® 1259 is an economical 4-1/2 IN ASME style process pressure gauge featuring stainless steel or Monel® wetted materials designed with numerous safety features. The 1259 features a solid front case design, and ranges from vacuum to 20000 PSI/(1400 BAR).
Ashcroft® Pressure Gauge, Pressure Gauge, Series/Model: Model 1259, 4-1/2 IN Dial, 0 - 100 PSI Measuring, Units Of Measure: PSI, 1/2 IN MNPT Lower Connection, Plus/Minus 0.5% Of Span (ASME B40.100 Grade 2A) Accuracy, Polybutylene Terephthalate Case, Glass Lens, Aluminum Pointer, 316L Stainless Steel Tube, 316L Stainless Steel Socket, Finish/Color: Black, Filled With: Dry, Remote, Stem, Surface Mounting, -20 To 250 DEG F, 5.81 IN Length, 5.81 IN Width, 3.36 IN Depth, Industry Standards: ASME B40.100, CE Marked, CRN Approved, UL 94-V-0
| Item Name | : | Pressure Gauge |
| Series/Model | : | Model 1259 |
| Dial Size | : | 4-1/2 IN |
| Measuring Range | : | 0 - 100 PSI |
| Units Of Measure | : | PSI |
| Connection | : | 1/2 IN MNPT Lower |
| Accuracy | : | Plus/Minus 0.5% Of Span (ASME B40.100 Grade 2A) |
| Case Material | : | Polybutylene Terephthalate |
| Lens Material | : | Glass |
| Pointer Material | : | Aluminum |
| Tube Material | : | 316L Stainless Steel |
| Socket Material | : | 316L Stainless Steel |
| Finish/Color | : | Black |
| Filled With | : | Dry |
| Mounting | : | Remote, Stem, Surface |
| Temperature Rating | : | -20 To 250 DEG F |
| Length | : | 5.81 IN |
| Width | : | 5.81 IN |
| Depth | : | 3.36 IN |
| Industry Standards | : | ASME B40.100, CE Marked, CRN Approved, UL 94-V-0 |
- Solid front safety case with pressure relief back
- 4-1/2 IN dial size
- Accuracy complies with ASME B40.100 grade 2A (plus/minus 0.5% of span)
