Ashcroft® Model 1125A 451125A04B30IMV&15# Differential Pressure Gauge, 4-1/2 IN Dial, 30 - 0 IN Hg, 0 - 15 PSID
- Manufacturer: Ashcroft Inc
- Brand: Ashcroft
- MGPN: GA451125A04B 30/15
- MPN: 451125A04B30IMV&15#
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
The Ashcroft® 1125/1125a gauges offer an economical solution for measuring high differential pressures for non-corrosive applications such as water, air or hydraulics and featuring a robust aluminum case.
Ashcroft® Differential Pressure Gauge, Type: Zero Center Dial, Differential Pressure Gauge, Series/Model: Model 1125A, 4-1/2 IN Dial, 30 - 0 IN Hg, 0 - 15 PSID Measuring, Units Of Measure: IN Hg, PSID, 1/2 IN MNPT Lower Back Connection, Plus/Minus 2-1-2% Of Span (ASME B40.100 Grade 1A) Accuracy, Aluminum Dial Face, Cast Aluminum Case, Glass Lens, Movement Material: Bronze, Bronze Tube, Bronze Socket, Finish/Color: Black, Filled With: Dry, Stem, Surface Mounting, -20 To 250 DEG F, 5.88 IN Length, 5.88 IN Width, 3.13 IN Depth, Industry Standards: ASME B40.100 Grade A, CE Marked, UKCA Approved
| Item Name | : | Differential Pressure Gauge |
| Type | : | Zero Center Dial |
| Series/Model | : | Model 1125A |
| Dial Size | : | 4-1/2 IN |
| Measuring Range | : | 30 - 0 IN Hg, 0 - 15 PSID |
| Units Of Measure | : | IN Hg, PSID |
| Connection | : | 1/2 IN MNPT Lower Back |
| Accuracy | : | Plus/Minus 2-1-2% Of Span (ASME B40.100 Grade 1A) |
| Dial Face | : | Aluminum |
| Case Material | : | Cast Aluminum |
| Lens Material | : | Glass |
| Movement Material | : | Bronze |
| Tube Material | : | Bronze |
| Socket Material | : | Bronze |
| Finish/Color | : | Black |
| Filled With | : | Dry |
| Mounting | : | Stem, Surface |
| Temperature Rating | : | -20 To 250 DEG F |
| Length | : | 5.88 IN |
| Width | : | 5.88 IN |
| Depth | : | 3.13 IN |
| Industry Standards | : | ASME B40.100 Grade A, CE Marked, UKCA Approved |
- Rugged design
- Built in back flange for surface or wall-mounting
- Zero center dial to indicate positive or negative pressure
- Compatible with diaphragm seals
- 1125A has 12 o'clock pointer position
