ASHCROFT GAUGE-304547
Ashcroft® Model 1001T 20W1001TH02BXUCZOT4400# Pressure Gauge, 2 IN Dial, 0 - 400 PSI, 1/4 IN MNPT Center Back
- Manufacturer: Ashcroft Inc
- Brand: Ashcroft
- MGPN: GA20W1001TH02B XUCZOT4 400
- MPN: 20W1001TH02BXUCZOT4400#
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
The Ashcroft® 1001T pressure gauge combines an aesthetic panel mount design with reliability and performance. Easily customizable, this model is an ideal solution for pressure measurement.
Ashcroft® Pressure Gauge, Type: Panel Mount, Pressure Gauge, Series/Model: Model 1001T, 2 IN Dial, 0 - 400 PSI Measuring, Units Of Measure: PSI, 1/4 IN MNPT Center Back Connection, Plus/Minus 3-2-3% Of Span (ASME B40.100 Grade B) Accuracy, Aluminum Dial Face, Steel Case, Polycarbonate Lens, Aluminum Pointer, Movement Material: PowerFlex™ With Polyester Segment, Bronze Tube, Brass Socket, Finish/Color: Black, Filled With: Dry, U-Clamp Mounting, -40 To 150 DEG F, 2.3 IN Length, 2.3 IN Width, 0.94 IN Depth, Industry Standards: ASME B40.100, CRN Approved, Additional Specifications: ZO: Bulk Pack, T4: 0.007 IN Orifice Restrictor
| Item Name | : | Pressure Gauge |
| Type | : | Panel Mount |
| Series/Model | : | Model 1001T |
| Dial Size | : | 2 IN |
| Measuring Range | : | 0 - 400 PSI |
| Units Of Measure | : | PSI |
| Connection | : | 1/4 IN MNPT Center Back |
| Accuracy | : | Plus/Minus 3-2-3% Of Span (ASME B40.100 Grade B) |
| Dial Face | : | Aluminum |
| Case Material | : | Steel |
| Lens Material | : | Polycarbonate |
| Pointer Material | : | Aluminum |
| Movement Material | : | PowerFlex™ With Polyester Segment |
| Tube Material | : | Bronze |
| Socket Material | : | Brass |
| Finish/Color | : | Black |
| Filled With | : | Dry |
| Mounting | : | U-Clamp |
| Temperature Rating | : | -40 To 150 DEG F |
| Length | : | 2.3 IN |
| Width | : | 2.3 IN |
| Depth | : | 0.94 IN |
| Industry Standards | : | ASME B40.100, CRN Approved |
| Additional Specifications | : | ZO: Bulk Pack, T4: 0.007 IN Orifice Restrictor |
- PowerFlex™ movement provides superior resistance to shock, vibration and pulsation
- TrueZero™ reduces reading errors by using a zero-box instead of conventional dial pins
- Standard panel mounting with U-clamp design
