ASHCROFT GAUGE
Ashcroft® Model 1005 15100501B15# Pressure Gauge, 1-1/2 IN Dial, 0 - 15 PSI, 1/8 IN MNPT Center Back, Steel Case
- Manufacturer: Ashcroft Inc
- Brand: Ashcroft
- MGPN: GA15100501B 0-15
- MPN: 15100501B15#
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
The Ashcroft® 1005, 1005P and 1005S series pressure gauges combine an aesthetic design with reliability and performance. Easily customizable, the extensive variety of case materials, connection locations and ranges, make these models an ideal solution for many pressure measurement installations.
Ashcroft® Pressure Gauge, Type: Commercial, Pressure Gauge, Series/Model: Model 1005, 1-1/2 IN Dial, 0 - 15 PSI Measuring, Units Of Measure: PSI, 1/8 IN MNPT Center Back Connection, Plus/Minus 3-2-3% Of Span (ASME B40.100 Grade B) Accuracy, Aluminum Dial Face, Steel Case, Polycarbonate Lens, Aluminum Pointer, Movement Material: PowerFlex™ With Polyester Segment, Bronze Tube, Brass Socket, Filled With: Dry, -40 To 150 DEG F, 1.62 IN Length, 1.62 IN Width, 0.99 IN Depth, Industry Standards: CRN Approved
| Item Name | : | Pressure Gauge |
| Type | : | Commercial |
| Series/Model | : | Model 1005 |
| Dial Size | : | 1-1/2 IN |
| Measuring Range | : | 0 - 15 PSI |
| Units Of Measure | : | PSI |
| Connection | : | 1/8 IN MNPT Center Back |
| Accuracy | : | Plus/Minus 3-2-3% Of Span (ASME B40.100 Grade B) |
| Dial Face | : | Aluminum |
| Case Material | : | Steel |
| Lens Material | : | Polycarbonate |
| Pointer Material | : | Aluminum |
| Movement Material | : | PowerFlex™ With Polyester Segment |
| Tube Material | : | Bronze |
| Socket Material | : | Brass |
| Filled With | : | Dry |
| Temperature Rating | : | -40 To 150 DEG F |
| Length | : | 1.62 IN |
| Width | : | 1.62 IN |
| Depth | : | 0.99 IN |
| Industry Standards | : | CRN Approved |
- PowerFlex™ movement provides superior resistance to shock, vibration and pulsation
- TrueZero™ reduces reading errors by using zero-box instead of conventional pins
- Customized dial printing
- Heat resistant push-in polycarbonate window
