3 C x C PRESS FLANGE
Apollo Valves ApolloPress® 8771 10061769 Companion Flange, 3 IN, Press X Flanged, Copper
- Manufacturer: Aalberts integrated piping systems (CONBRACO)
- Brand: Apollo Valves
- MGPN: APOLLO PRESS FLG CXC 3
- MPN: 10061769
- UPC: 00683264617698
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
The ApolloPress® 8771 large diameter press 150 LB companion flange features a lead-free dezincification-resistant copper body, a patented stainless steel solid cross section grab ring, a nylon separation ring and EDPM O-ring. The black powder-coating provides separation of dissimilar metals preventing electrolysis. ApolloPress® products are manufactured utilizing proven ASTM materials and standards.
Apollo Valves ApolloPress® 8771 Large Diameter Straight Companion Flange, 3 IN Nominal, Press X Flanged Connection, 0.08 IN Wall Thickness, Copper, 3.13 IN Outside Diameter, 7-1/2 IN Length, 300 PSI Maximum Pressure, 32 - 250 DEG F, Industry Standards: CRN, FA, IAPMO/ANSI/CAN Z1117 Certified, ICC Certified, NSF/ANSI 372 Certified, NSF/ANSI 61 Certified, cULus Listed, ULC Listed, Wrot: No, Lead Free: Yes, Additional Specifications: Includes: EPDM Sealing Elements, Buffer Stud and Connection Indicator
| Sub Brand | : | ApolloPress® |
| Item Name | : | Companion Flange |
| Type | : | Large Diameter, Straight |
| Series/Model | : | 8771 |
| Nominal Size | : | 3 IN |
| Connection Type | : | Press X Flanged |
| Wall Thickness | : | 0.08 IN |
| Material | : | Copper |
| Outside Diameter | : | 3.13 IN |
| Length | : | 7-1/2 IN |
| Maximum Pressure | : | 300 PSI |
| Temperature Rating | : | 32 - 250 DEG F |
| Industry Standards | : | CRN, FA, IAPMO/ANSI/CAN Z1117 Certified, ICC Certified, NSF/ANSI 372 Certified, NSF/ANSI 61 Certified, cULus Listed, ULC Listed |
| Wrot | : | No |
| Lead Free | : | Yes |
| Additional Specifications | : | Includes: EPDM Sealing Elements, Buffer Stud and Connection Indicator |
- Black powder-coated steel flange base
- Leak Before Press® technology
- Visual element, break away band
