2-1/2 PRESS PC641 P X FLG ADAPTER
Nibco Press System® Steel Large Diameter Companion Flange, 2-1/2 IN, Press X Flanged
- Manufacturer: NIBCO
- Brand: NIBCO
- MGPN: 250CUNPFLA
- MPN: 9145500PC
- UPC: 039923379078
- UOM: EA
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
The Nibco® Press System® companion flange features an inboard bead and EPDM o-ring. Simply applying pressure from a pressing tool tightens the O-ring onto the tube, ensuring a clean, watertight seal in seconds with no flame, solder or flux. The companion flange has a copper press connection and steel flanged end connection. The fitting provides a method for adapting a press connection to a flange connection.
| Sub Brand | : | Press System® |
| Item Name | : | Companion Flange |
| Type | : | Large Diameter |
| Series/Model | : | Model PC641 |
| Nominal Size | : | 2-1/2 IN |
| Outside Diameter | : | 7 IN |
| Connection Type | : | Press X Flanged |
| Thickness | : | 3/4 IN |
| Bolt Circle Diameter | : | 5-1/2 IN |
| Bolt Hole Diameter | : | 3/4 IN |
| Length | : | 2-25/32 IN |
| Material | : | Steel |
| Material Standard | : | ASTM A515 Grade 60, ASTM B88 |
| Material Specification | : | UNS C12200 |
| Maximum Pressure | : | 200 PSI |
| Temperature Rating | : | -25 To 200 DEG F |
| Industry Standards | : | ASME B16.51, CSA MSE 13, PS-117 And UPC Certified |
| Additional Specifications | : | Lead Free: Yes |
- Operating pressure 200 PSI CWP
- Temperature range -20 to 250 DEG F
- Lead-free
- Dezincification-resistant
- Flange ring - steel plate meeting minimum tensile requirements of grade 60 per ASTM A515
