8 WARREN 3155-8 150 CS FLGD CHECK VALVE
Warren 3155-8 Class 150 Cast Carbon Steel Swing Check Valve, 8 IN, Flanged
- Manufacturer: Warren Valve
- Brand: Warren Valve
- MGPN: 8003155C8CV
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
| Item Name | : | Swing Check Valve |
| Series/Model | : | Model 3155-8 |
| Nominal Size | : | 8 IN |
| Connection Type | : | Flanged |
| Flow Rate | : | 799.4 GPM |
| Pressure Class | : | Class 150 |
| Opening Size | : | 8 IN |
| Body Material | : | Cast Carbon Steel |
| Trim Material | : | Carbon Steel Disc |
| Material Standard | : | Body: ASTM A216 Grade WCB, Disc: ASTM A105/A216 Grade WCB Plus 13% Chromium |
| Industry Standards | : | API 600, 598, MSS-SP-55 Compliant, ANSI B16.5, B16.34 |
| Width | : | 19-1/2 IN |
| Lead Free | : | No |
| Other Physical Dimension | : | 13-1/2 IN Flange Diameter, 1.12 IN Flange Thickness, 12.2 IN Inlet Center To Top Of Valve |
- Warren Valve's cast carbon steel check valve product line includes 1/2 - 24 IN, ANSI pressure class 150# - 300# - 600# - 900# - 1500# - 2500#
- Bolted cover
- Exterior hinge pin
- Swing type disc
- Graphite gasket
Brochure/Catalog
