4-1/2 0-60 PSI 1/4 LM PRESSURE GAUGE DRY
Trerice 620B 304 Stainless Steel 1/4 IN MNPT Lower Mount Dry Contractor Pressure Gauge, 0 - 60 PSI, 4-1/2 IN Dial
- Manufacturer: Trerice
- Brand: Trerice
- MGPN: 450060PGT
- MPN: 620B4502LA60
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
Contractor Pressure Gauge, Series/Model: Model 620B, 4-1/2 IN Dial, Measuring Range: 0 - 60 PSI, Units Of Measure: PSI, Connection: 1/4 IN MNPT Lower, Accuracy: Plus/Minus 1% Full Scale (ASME Grade 1A), Graduations: 1 Smallest, 10 Largest, Dial Face: Aluminum, White Background With Black Graduations And Markings, 304 Stainless Steel Case, Acrylic Lens, Brass Movement, Tube Material: Bronze, Brass Socket, Dry Filled With, Mounting: Stem, Temperature Rating: 212 DEG F, Length: 4.96 IN, 4.96 IN Width, 1.16 IN Depth, Industry Standards: ASME B40.100, CRN Approved
| Item Name | : | Contractor Pressure Gauge |
| Series/Model | : | Model 620B |
| Dial Size | : | 4-1/2 IN |
| Measuring Range | : | 0 - 60 PSI |
| Units Of Measure | : | PSI |
| Connection | : | 1/4 IN MNPT Lower |
| Accuracy | : | Plus/Minus 1% Full Scale (ASME Grade 1A) |
| Graduations | : | 1 Smallest, 10 Largest |
| Dial Face | : | Aluminum, White Background With Black Graduations And Markings |
| Case Material | : | 304 Stainless Steel |
| Lens Material | : | Acrylic |
| Movement Material | : | Brass |
| Tube Material | : | Bronze |
| Socket Material | : | Brass |
| Filled With | : | Dry |
| Mounting | : | Stem |
| Temperature Rating | : | 212 DEG F |
| Length | : | 4.96 IN |
| Width | : | 4.96 IN |
| Depth | : | 1.16 IN |
| Industry Standards | : | ASME B40.100, CRN Approved |
The 620B Trerice contractor gauge is designed to service the general pressure measurement requirements of the construction industry. The 620B offers high reliability at an economic price. This gauge features a corrosion-resistant, stainless steel case and acrylic window. Wetted parts are lead-free (PBF) brass.
- Stainless steel case
- Recalibrator screw
Instruction/Installation Manual
