Our 160 series pumps are robust, high-performance solutions suitable for various commercial applications, including septic tanks, low-pressure pipes (LPP), or enhanced flow STEP systems. These heavy-duty sump and effluent pumps are constructed from durable cast iron with a corrosion-resistant, powder-coated epoxy finish. Together with their no-clog vortex impeller, these elements give you a commercial sump pump you can count on for smooth, reliable operation. Whether you choose an automatic or non-automatic configuration, you can expect these pumps to maintain 3450 RPM and pump out 100 GPM. Each device we offer undergoes rigorous computerized testing and comes with a one-year limited warranty to give you peace of mind.

Automatic High Head Flow-Mate Submersible Sump Pump, Series/Model: Series 160, Size: 1-1/2 IN, 86.5 FT Maximum Head, Flow Rate: 100 GPM, 0.5 HP HP Rating, Voltage Rating: 115 VAC, Amperage Rating: 15 A, 60 HZ Frequency Rating, 1 PH Phase, 3450 RPM RPM Rating, Cast Iron Housing, Bronze Impeller, SAE 1117 Carbon Steel Shaft, Connection Type: NPT, Finish/Color: Epoxy Coated, Temperature Rating: 130 DEG F, Industry Standards: C/US Certified To CSA Standard C22.2 Number 108, Tested To UL Standard UL778, SSPMA Certified, 12-3/4 IN Width, 19-5/16 IN Height, Additional Specifications: Maximum Diameter Solids: 3/4 IN, Off Point: 14-3/4 IN, On Point: 5 IN, Cord Length: 20 FT

• Durable, cast iron constructed switch case, base, motor and pump housing
• Corrosion-resistant, powder-coated epoxy finish
• Oil-filled, hermetically-sealed, automatic reset thermal overload protected (1 PH only) motor
• Upper and lower ball bearing running in bath of oil
• Carbon and ceramic shaft seal
• Maximum temperature for effluent or dewatering: 130 DEG F (54 DEG C) (E/D: 140 DEG F/60 DEG C)
• No screens to clog
• Neoprene square ring and gasket
• Stainless steel screws, bolts, float rod, handle, guard, arm and seal assembly
• Passes 3/4 IN (19 MM) spherical solids
• 100% of units are computerized tested
• 1 YR limited warranty

• Technical Drawing https://www.macombgroup.com//ASSETS/DOCUMENTS/ITEMS/EN/M163_Tech.pdf
• Brochure https://www.macombgroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Zoeller_M163_Brochure.pdf
• Specification Sheet https://www.macombgroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Zoeller_M163_Specification_Sheet.pdf
• Specification Sheet_1 https://www.macombgroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Zoeller_M163_Specification_Sheet_1.pdf
