2 BRZ 3-WAY FP BALL VALVE
Apollo Valves 77-640 Cast Bronze Latch-Lock Lever Handle Full-Port Ball Valve, 2 IN, FNPT
- Manufacturer: Aalberts integrated piping systems (CONBRACO)
- Brand: Apollo Valves
- MGPN: 2007764827BV
- MPN: 77-648-27
- UPC: 670750322761
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
Full-Port Ball Valve, Series/Model: Series 77-640, Nominal Size: 2 IN, Connection Type: FNPT, Ports/Ways: 3-Way, Pressure Rating: 400 PSI (CWP), Temperature Rating: -50 To 500 DEG F, Cast Bronze Body Material, Latch-Lock Lever Handle Operator Type, Handle Material: Stainless Steel, Stem Material: 316 Stainless Steel, Trim Material: 316 Stainless Steel Ball, Packing Material: MPTFE Stem, Brass Gland, Seat Material: MPTFE, Material Standard: Body: ASTM B584, Ball And Stem: ASTM A276, Gland: ASTM B16, Material Specification: Body: UNS C84400, 5.36 IN Width, 5.4 IN Height, Lead Free: No, Additional Specifications: Flow Co-Efficient (Cv): 190
| Item Name | : | Ball Valve |
| Type | : | Full-Port |
| Series/Model | : | Series 77-640 |
| Nominal Size | : | 2 IN |
| Connection Type | : | FNPT |
| Number Of Ports/Ways | : | 3-Way |
| Pressure Rating | : | 400 PSI (CWP) |
| Temperature Rating | : | -50 To 500 DEG F |
| Body Material | : | Cast Bronze |
| Operator Type | : | Latch-Lock Lever Handle |
| Handle Material | : | Stainless Steel |
| Stem Material | : | 316 Stainless Steel |
| Trim Material | : | 316 Stainless Steel Ball |
| Packing Material | : | MPTFE Stem |
| Gland Material | : | Brass |
| Seat Material | : | MPTFE |
| Material Standard | : | Body: ASTM B584, Ball And Stem: ASTM A276, Gland: ASTM B16 |
| Material Specification | : | Body: UNS C84400 |
| Width | : | 5.36 IN |
| Height | : | 5.4 IN |
| Lead Free | : | No |
| Additional Specifications | : | Flow Co-Efficient (Cv): 190 |
- Cast body and retainer
- MPTFE seats and stem packing
- Four bolt ISO mounting ISO 5211 (F07)
- Blow-out proof stem design
- Adjustable packing gland
- SS lever and nut
- Latch lock lever
Specification Sheet
