3/4 BRZ UNI-BODY BALL VALVE
Apollo Valves 9A-100 Bronze Round Handle Uni-Body Compact Heavy Pattern Ball Valve, 3/4 IN, FNPT
- Manufacturer: Aalberts integrated piping systems (CONBRACO)
- Brand: Apollo Valves
- MGPN: 0759A10415BV
- MPN: 9A-104-15
- UPC: 670750787362
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
Uni-Body Compact Heavy Pattern Ball Valve, Series/Model: Series 9A-100, Nominal Size: 3/4 IN, Connection Type: FNPT, Pressure Rating: 600 PSI (CWP), Temperature Rating: -50 To 500 DEG F, Bronze Body Material, Round Handle Operator Type, Handle Material: Steel, Stem Material: Brass, Trim Material: Brass Ball, Packing Material: MPTFE Stem, Seat Material: RPTFE, Material Standard: Body: ASTM B584, Ball And Stem: ASTM B16, Material Specification: Body: UNS C84400, Finish/Color: Chrome Plated Ball, Industry Standards: MSS-SP-110 Compliant, 2.84 IN Width, Lead Free: No, Other Physical Dimension: 1.84 IN Inlet Center To Top Of Handle, 3.87 IN Handle Length, Additional Specifications: Flow Co-Efficient (Cv): 34
| Item Name | : | Ball Valve |
| Type | : | Uni-Body, Compact, Heavy Pattern |
| Series/Model | : | Series 9A-100 |
| Nominal Size | : | 3/4 IN |
| Connection Type | : | FNPT |
| Pressure Rating | : | 600 PSI (CWP) |
| Temperature Rating | : | -50 To 500 DEG F |
| Body Material | : | Bronze |
| Operator Type | : | Round Handle |
| Handle Material | : | Steel |
| Stem Material | : | Brass |
| Trim Material | : | Brass Ball |
| Packing Material | : | MPTFE Stem |
| Seat Material | : | RPTFE |
| Material Standard | : | Body: ASTM B584, Ball And Stem: ASTM B16 |
| Material Specification | : | Body: UNS C84400 |
| Finish/Color | : | Chrome Plated Ball |
| Industry Standards | : | MSS-SP-110 Compliant |
| Width | : | 2.84 IN |
| Lead Free | : | No |
| Other Physical Dimension | : | 1.84 IN Inlet Center To Top Of Handle, 3.87 IN Handle Length |
| Additional Specifications | : | Flow Co-Efficient (Cv): 34 |
| Weight | : | 1.100 LB |
- Static grounding devices
- Blow-out proof stem design
- Reinforced seats and seals
- Adjustable packing gland
- 1-piece bronze body
- RPTFE stem bearing, vinyl grip, B16 retainer, gland nut, steel lever nut, stainless steel ground spring
Instruction/Installation Manual
