1-1/2 BRZ FP SWEAT BALL VALVE
Apollo Valves 94A Forged Brass Lever Handle 2-Piece Full-Port In-Line Standard Ball Valve, 1-1/2 IN, Solder
- Manufacturer: Aalberts integrated piping systems (CONBRACO)
- Brand: Apollo Valves
- MGPN: 15094A20701BV
- MPN: 94A-207-01
- UPC: 670750823862
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- See All Availability
-
Price:
2-Piece Full-Port In-Line Standard Ball Valve, Series/Model: Series 94A, Nominal Size: 1-1/2 IN, Connection Type: Solder, Pressure Rating: 600 PSI (CWP), Temperature Rating: 0 - 400 DEG F, 1.575 IN Opening, Forged Brass Body Material, Lever Handle Operator Type, Handle Material: Corrosion Resistant Steel, Stem Material: Brass, Trim Material: Brass Ball, Packing Material: PTFE Stem, Seat Material: PTFE, Finish/Color: Chrome Plated Ball And Stem, Industry Standards: MSS-SP-110 Compliant, CSA Certified, UL Listed, FM Approved, 4.425 IN Width, Lead Free: No, Other Physical Dimension: 3.169 IN Inlet Center To Top Of Handle, 5.512 IN Handle Length, Additional Specifications: Flow Co-Efficient (Cv): 268
| Item Name | : | In-Line Standard Ball Valve |
| Type | : | 2-Piece, Full-Port |
| Series/Model | : | Series 94A |
| Nominal Size | : | 1-1/2 IN |
| Connection Type | : | Solder |
| Pressure Rating | : | 600 PSI (CWP) |
| Temperature Rating | : | 0 - 400 DEG F |
| Opening Size | : | 1.575 IN |
| Body Material | : | Forged Brass |
| Operator Type | : | Lever Handle |
| Handle Material | : | Corrosion Resistant Steel |
| Stem Material | : | Brass |
| Trim Material | : | Brass Ball |
| Packing Material | : | PTFE Stem |
| Seat Material | : | PTFE |
| Finish/Color | : | Chrome Plated Ball And Stem |
| Industry Standards | : | MSS-SP-110 Compliant, CSA Certified, UL Listed, FM Approved |
| Width | : | 4.425 IN |
| Lead Free | : | No |
| Other Physical Dimension | : | 3.169 IN Inlet Center To Top Of Handle, 5.512 IN Handle Length |
| Additional Specifications | : | Flow Co-Efficient (Cv): 268 |
| Weight | : | 2.170 LB |
The Apollo® International™ 94A forged brass ball valve combines reliable operation with maximum economy. ideal for general flow control applications including HVAC, fuel gases, and fire protection trim and drain etc. valves include most pertinent agency approvals.
- 2-piece, full-port design
- Blow-out proof stem design
- Adjustable stem packing nut
- 100% factory tested
- Stem seal o-ring (solder version 1/2 - 2 IN)
- MSS SP-110 ball valves
- 2 YR warranty
Instruction/Installation Manual
