Utility Pressure Gauge, Series/Model: Model 800B, 2-1/2 IN Dial, Measuring Range: 0 - 30 PSI, Units Of Measure: PSI, Connection: 1/4 IN MNPT Lower, Accuracy: Plus/Minus 1.6% Full Scale, Graduations: 0.5 Smallest, 5 Largest, Dial Face: Aluminum, White Background With Black Graduations And Markings, Black Drawn Steel Case, Acrylic Lens, Brass Movement, Tube Material: Bronze, Brass Socket, Dry Filled With, Mounting: Stem, Temperature Rating: 180 DEG F, Length: 2.48 IN, 2.48 IN Width, 1.16 IN Depth, Industry Standards: ASME B40.100, CRN Approved

The Trerice 800B utility gauge is designed for general pressure indication requirements. This gauge provides reliable service at an economical cost. Wetted parts are bronze tube and lead-free (PBF) brass socket.

• Economically priced gauges suited for a variety of general applications
• Black finished steel case

• Instruction/Installation Manual https://www.macombgroup.com//ASSETS/DOCUMENTS/ITEMS/EN/4500200PPGS_Inst.pdf
• Catalog https://www.macombgroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Trerice_107-001_Catalog.pdf
• Specification Sheet https://www.macombgroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Trerice_800B1501BA090_Specification_Sheet.pdf
